Specification:
Outer Diameters: Standard models from 480 mm to 5000 mm (18" to 196")
Capacity:
Maximum Thrust: 45,200 KN (10,200,000 lbs)
Maximum Moment: 30,672 KN-M (41,584,000 ft-lbs)
Gearing: Non-gear, External Gear, Internal Gear
Maximum Moment: 30,672 KN-M (41,584,000 ft-lbs)
Gearing: Non-gear, External Gear, Internal Gear
Catalog Downloads:
Cross Roller Slewing Bearing (Ungear).pdf
Cross Roller Slewing Bearing (External Gear).pdf
Cross Roller Slewing Bearing (Internal Gear).pdf
Design Your Bearings Worksheet
Cross Roller Slewing Bearing (External Gear).pdf
Cross Roller Slewing Bearing (Internal Gear).pdf
Design Your Bearings Worksheet
Material:
| Material | USA | China | Germany | British |
| Alloy Steel | AISI 4140 | GB42CrMo | DIN42CrMo4 | BS708A42 |
| Carbon Steel | AISI 1045 | GB45 | DINCK45 | BS060A42 |
